OBD2 Breakout Box OBDII Protocol Detector CAN Bus Test Breakout Box Detection
OBD2 Breakout Box OBDII Protocol Detector CAN Bus Test Breakout Box Detection
Specifications
| Return Shipping Will Be Paid By | Buyer |
| Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Unbranded |
| Type | OBDII Protocol Detector |
| Warranty | 1 Year |
| Vehicle Type | Heavy Duty/Commercial |
| Manufacturer Part Number | Does Not Apply |
| OBD Interface | OBDII |
| Country/Region Of Manufacture | China |
| Supported System | OBD Protocol Test |
| Connectivity | ECU Breakout Box |
OBD2 Breakout Box - Protocol Detector OBD2 breakout box is an automotive tool for the car OBD line signal judgment and signal transfer which offers easy access to the OBD2 connector for monitoring signals of protocol，power and grounds conveniently and safely. In addition, OBD2 protocol detector has male and female header connectors,you can place the junction box between the diagnostic tool and the vehicle,which is more convenient to measure the CAN bus signal. 1. In the process of using decoder, error can be found and diagnosed OBD connector link. 2. You can monitor the OBD interface voltage and ground, showed low voltage. Display diagnostic stitching error. 3. Jump for OBD interface signals. Signal lines such as decoder of 7 to 15 vehicles online. 4. Rapid detection of OBD2 diagnostic connector whether every stitch of the normal communication. 5. Replace the battery, save the car data function. When replace the battery, plug OBD2 connector into the car, at the same time connect additional power to the control box, so that ensure vehicle data is not lost. Using Our OBD2 Breakout Box Can Quickly Determine Car OBD Signal Receiving Details of Led Light-Emitting Diode Display Red LED Signal Light: If the car power supply is detected as normal, the red LED of pin 16 will always be on. Green LED Signal Light: If the car is detected grounded normally, the green LED of pin 4 and 5 will always be on. Yellow LED Signal Light: When the code reader communicates with the vehicle, the yellow LED on pin 2 or 6/7/10/14/15 will occur a waveform signal. Main function : 1. OBD Signal Detects : Sixteen Led lights detect the OBD signal . Leds at pin-out display signal detection, Flashing Leds for ECU activity,the led can Detect PWM (J1850) VPW (J1850) ISO 9141-2,DIS/ISO 14230-4 (12V car and 24V diesel)CAN bus (J-2284) (SAEJ1939) Power signal and ground signal . 2 .OBD2 Male to female extension line: The Length is 90CM of the line can Connect between Diagnostic Link Connector (DLC) and scan tool. Delivery detailsReturn PolicyAbout UsContact usPaymentDelivery details1.We will ship according to your EBAY address but sorry that we can not accept P.O.BOX address.Please make sure it’s correct . This will help your product to be received safely and quickly! 2.International Buyers Please Note:1) Please check with your country customs office to determine what these additional Import tariffs costs will be prior to bidding / buying.2) It's the buyer's responsibility to complete clearance when parcel reached your Customs. We are Not responsible for buyers's local taxes, please consult local Customs for Tax Details. Customs rates vary from country to country, please understand.3. Any further queries, please don't hesitate to email us. Thank you Return PolicyPlease return the item within 30 days after receiving if you are not happy with your purchasing.All returns are expected to be in original conditions, please email us first for return address and instructions. About UsWe have been in the automotive repair tool industry for many years and our company was founded to be trustworthy. With warehouses and enough goods in Germany USA UK, we can assure you of fast delivery of parcels and excellent service! Contact usWe are committed to your satisfaction after your purchase.If you are not satisfied with your purchase in any way please give us an opportunity to try and make it right before leaving feedback.We will answer your questions within 1 working days.Customer Service Hours: M-F: 9:30AM - 18:00PM BST (Beijing Standard Time)Payment1. We accept PayPal , Credit card (Visa, Eurocard/MasterCard, Amex, and Switch or Visa/Delta) payment can be accepted ONLY through EBAY. 2. Other payment methods (Bank transfer, Cheque, etc.) are NOT acceptable ! 3. Please make the payment within 3 day
